Our new range of manual arm barriers have a slimline design and is suitable for use protecting car parks and other entrances to commercial property sites. This barrier is ideal for areas where access only needs to be restricted during certain times of the

The barrier can be locked in the raised and lowered positions offering complete peace of mind when the parking area is not in use.

Manufactured from galvanised mild steel with an aluminium boom, the body of the barrier is powder coated blue as standard. Other colours are available on request, RAL codes must be stated at time of order. Pogo sticks, folding skirts and double span barriers are available on request.

Locking the Manual Arm Barrier at the Catch Post is an additional option,
please state at the time of order if this is required

Available in 3, 4, 5, 6 and 7 metre lengths. Please select a size from the menu.


  • Galvanised mild steel construction, painted blue as standard.
  • Lockable in the raised and lowered position
  • Single boom up to 7m.
  • Double barriers available for larger road widths.
  • Skirt option available up to 6m (skirt is aluminium).


  • 1208mm (approx) overall height
  • Boom lengths 3000mm- 7000mm
  • Ragged barrier 600mm below ground
  • Ragged catch post 300mm below ground for catch post


  • A recommended concrete foundation base of 600x600x500mm
  • M16 Bolts (4 per barrier base)
  • M12 Bolts (4 per catch post)
  • Additionally, barrier is also available for ragged finish if it needs casting into ground (600mm below ground for ragged version)
  • Catch post can also be ragged, (allow 300mm below ground)

Have a question about Manual Rising Arm Barrier 3m -7m ?


A steel manual arm barrier ideal for controlling vehicle accesss to a car parks, construction sites, schools & colleges, and to any site that requires restricted access
